EC-600WM, EC-600WI, EC-600WL
![[photo] Lower G.I. scope](https://asset.fujifilm.com/www/mx/files/2024-07/29173ff0dbe91b443284f021f8575ca3/pic_colonoscope_01.jpg)
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/mx/files/2024-07/d0f4cb4aa4ba6493441fe91f1d365ddc/pic_colonoscope_02.jpg)
![[photo] Flexible tip of scope bent downward with forceps sticking out](https://asset.fujifilm.com/www/mx/files/2024-07/89900c6edb4921d7500269d24776b856/pic_colonoscope_03.jpg)
- Viewing direction
0°(Forward)
- Field of view
140°
- Observation range
2-100 mm
- Distal end diameter
12.0 mm
- Insertion tube diameter
12.0 mm
- Minimum diameter of instrument channel
3.8 mm
- Bending capability
UP 180° / DOWN 180°
RIGHT 160° / LEFT 160°- Working length
1,330 mm（M） / 1,520 mm（I） / 1,690 mm（L）
- Total length
1,630 mm（M） / 1,820 mm（I） / 1,990 mm（L）
- Water Jet
Available
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/mx/files/2024-07/928f18916368dcb65dcbd7b225f4f3d9/fig_colonoscope_01.jpg)
![[image] Scope moves 180 degrees up/down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/mx/files/2024-07/22b20de956cc77006b2e9cc28f6344ac/fig_colonoscope_02.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/mx/files/2024-07/b54a87467ef7c62c386649506c9ff612/fig_colonoscope_03.jpg)
EC-600ZW/M, EC-600ZW/L
![[photo] Lower G.I. scope](https://asset.fujifilm.com/www/mx/files/2020-05/857822c86036d97c0e39c649bb6c398b/pic_colonoscope_04.jpg)
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/mx/files/2020-05/d6890bae8d4a680cc753a5917d533f1c/pic_colonoscope_05.jpg)
![[photo] Flexible tip of scope bent downward with forceps sticking out](https://asset.fujifilm.com/www/mx/files/2020-05/ba346c57df1fb521f9e13139818aeaed/pic_colonoscope_06.jpg)
- Viewing direction
0°(Forward)
- Field of view
Normal: 140° / Closest: 56°
- Observation range
1.5-100 mm
Normal: 3-100 mm
Closest: 1.5-2.5 mm- Distal end diameter
12.8mm
- Insertion tube diameter
12.8mm
- Minimum diameter of instrument channel
3.8mm
- Bending capability
UP 180° / DOWN 180°
RIGHT 160° / LEFT 160- Working length
1,330 / 1,690 mm
- Total length
1,630 / 1,990 mm
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/mx/files/2020-05/5e02e84239f601789350db41024d69e5/fig_colonoscope_04.jpg)
![[image] Scope moves 180 degrees up/down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/mx/files/2020-05/bc04dfe88f07f8a333478dca06eedbac/fig_colonoscope_05.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/mx/files/2020-05/37e41ab85f31620b57b8102efa2c0320/fig_colonoscope_06.jpg)
EC-580RD/M, EC-580RD/L
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/mx/files/2024-07/ba2e0a0989a0e4017c7f0d9dc6d72329/pic_colonoscope_08.jpg)
![[photo] Flexible tip of scope bent downward to the side](https://asset.fujifilm.com/www/mx/files/2024-07/6d85c7bfb4f0aa3e3196ccca9ceaf197/pic_colonoscope_09.jpg)
- Viewing direction
0°(Forward)
- Field of view
140°
- Observation range
3-100mm
- Distal end diameter
9.8mm
- Insertion tube diameter
10.5mm
- Minimum diameter of instrument channel
3.2mm
- Bending capability
UP 210° / DOWN 160°
RIGHT 160° / LEFT 160°- Working length
EC-580RD/M
1,330mmEC-580RD/L
1,690mm- Total length
EC-580RD/M
1,630mmEC-580RD/L
1,990mm- Water Jet
Available
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/mx/files/2024-07/f04554ab8e85044e77a0c67665df2233/fig_colonoscope_07.jpg)
![[image] Scope moves 210 degrees up/ 160 degrees down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/mx/files/2024-07/2f5070096f55014f64bd823e268c02c3/fig_colonoscope_08.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/mx/files/2024-07/fbd024f2ac92f467f2aa61ef9c65cc81/fig_colonoscope_09.jpg)
