High-resolution bronchoscope with improved operability thanks to 210°upward bending capability and 2.2mm diameter instrument channel.
- Field of view
120°
- Observation range
2-100mm
- Distal end diameter
5.3mm
- Insertion tube diameter
5.1mm
- Minimum diameter of instrument channel
2.2mm
- Bending capability
UP 210° / DOWN 130°
- Working length
600mm
- Total length
870mm
- Product : Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable
![](https://asset.fujifilm.com/www/mm/files/2020-05/4e91955027812cf691786eeff8ed5dbf/fig_bronchoscopes_01.jpg)
![](https://asset.fujifilm.com/www/mm/files/2020-05/8df5556524ba2af39f5387ace1ff683f/fig_bronchoscopes_02.jpg)
![](https://asset.fujifilm.com/www/mm/files/2020-05/031da3abc38d16453be31784fef4902d/fig_bronchoscopes_03.jpg)
High-resolution bronchoscope to support efficient treatment.
- Field of view
120°
- Observation range
2-100mm
- Distal end diameter
5.8mm
- Insertion tube diameter
5.9mm
- Minimum diameter of instrument channel
2.8mm
- Bending capability
UP 180° / DOWN 130°
- Working length
600mm
- Total length
870mm
- Product : Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable
