DRI-CHEM NX500 : Parameters and Specifications

The content on this page is intended to healthcare professionals and equivalents.

Parameters

Classification		Parameter	Measurement range ^*1				Measurement time (min.)
Classification		Parameter	Unit (A)		Unit (B)		Measurement time (min.)
Biochemical tests	Enzymes	ALP	14 – 1183	U/L	0.23 – 19.76	μ Kat/L	4
		AMYL	10 – 1800	U/L	0.17 – 30.06	μ Kat/L	5
		CHE	5 – 500	U/L	0.08 – 8.35	μ Kat/L	4.5
		CKMB	1 – 300	U/L	0.02 – 5.01	μ Kat/L	5
		CPK	10 – 2000	U/L	0.17 – 33.40	μ Kat/L	4
		GGT	10 – 1200	U/L	0.17 – 20.04	μ Kat/L	5
		GOT/AST	10 – 1000	U/L	0.17 – 16.70	μ Kat/L	4
		GPT/ALT	10 – 1000	U/L	0.17 – 16.70	μ Kat/L	4
		LAP	10 – 500	U/L	0.17 – 8.35	μ Kat/L	4
		LDH	50 – 900	U/L	0.84 – 15.03	μ Kat/L	2
		LIP	20 – 1000	U/L	0.33 – 16.70	μ Kat/L	5
	General chemistry	ALB	1.0 – 6.0	g/dL	10 – 60	g/L	6
		BUN	5.0 – 140.0	mg/dL	1.79 – 49.98	mmol/L	4
		Ca	4.0 – 16.0	mg/dL	1.00 – 4.00	mmol/L	4
		CRE	0.2 – 24.0	mg/dL	18 – 2122	μmol/L	5
		DBIL	0.1 – 16.0	mg/dL	2 – 274	μmol/L	5
		GLU	10 – 600	mg/dL	0.6 – 33.3	mmol/L	6
		HDL-C	10 – 110	mg/dL	0.26 – 2.84	mmol/L	6
		IP	0.5 – 15.0	mg/dL	0.16 – 4.84	mmol/L	5
		Mg	0.2 – 7.0	mg/dL	0.08 – 2.88	mmol/L	4.5
		NH₃	10 – 500	μg /dL	7 – 357	μmol/L	2
		TBIL	0.2 – 30.0	mg/dL	3 – 513	μmol/L	6
		TCHO	50 – 450	mg/dL	1.29 – 11.64	mmol/L	6
		TCO₂	5 – 40	mmol/L	5 – 40	mmol/L	5
		TG	10 – 500	mg/dL	0.11 – 5.65	mmol/L	4
		TP	2.0 – 11.0	g/dL	20 – 110	g/L	6
		UA	0.5 – 18.0	mg/dL	30 – 1071	μmol/L	4
	Electrolytes	Na	75 – 250	mEq/L	75 – 250	mmol/L	1
		K	1.0 – 14.0	mEq/L	1.0 – 14.0	mmol/L
		Cl	50 – 175	mEq/L	50 – 175	mmol/L
Immunological test		CRP	0.3 – 7.0	mg/dL	3 – 70	mg/L	5
Comprehensive S-panel		TP, ALB, ALP, GLU, TBIL, IP, TCHO, GGT, GPT/ALT, Ca, CRE, BUN
Small Screening S-panel		ALP, TBIL, GGT, GPT/ALT, CRE, GOT/AST

* There are parameters which may not be available in your area. For details please contact your local distributor.
*1 Unit (A) and (B) is available

Calculations

Calculated Parameter	Indication	Unit	Equation
LDL Cholesterol	LDL	mg/dL	LDL-C = TCHO value - (HDL-C vlaue + TG value/5)
LDL Cholesterol	LDL	mmol/L	LDL-C = TCHO value - (HDL-C value + TG value/2.2)
non-HDL Cholesterol	non-HDL	mg/dL or mmol/L	non-HDL = TCHO value - HDL-C value
Globulin	GLOB	g/dL or g/L	GLOB = TP value - ALB value
Albumin/Globulin ratio	ALB/GLOB	-	ALB/GLOB = ALB value / (TP value - ALB value)
BUN/Creatinine ratio	BUN/CRE	-	BUN/CRE = BUN value / CRE value
Anion Gap	Anion Gap	mEq/L or mmol/L	Anion Gap = Na value - (Cl value + TCO₂ value)

Main specifications

Measurement test: Colorimetry 28 tests
Electrolytes 3 tests
Throughput: Colorimetry 120 test/hour
Combined 128 test/hour
Number of sample rack: 1
Number of incubator cell: Colorimetry 12, Electrolytes 1
Measurement time: Colorimetry 2 to 6 minutes/test,
Electrolytes 1 minute/3 tests (Na-K-Cl)
Sample type: Plasma, Serum, Whole blood^*2
Sample volume: Colorimetry 10μL/test,
Electrolytes 50μL/3 tests (Na-K-Cl), CRP 5μL/test
Data transmission to PC: USB 2.0 or RS-232C Serial
D-Sub 9 pin -9 pin cross cable
Data print: Thermal Printer
Electrical requirements: AC 100-240V, 50/60Hz, 2.5-1.1A
Dimensions: 470 (W) 5 360 (D) 5 420 (H) mm
Weight: NX500 Approx. 25kg, NX500i Approx. 24kg
Operating temperature: 15 to 32˚C (59 to 89F)
Operating humidity: 30 to 80%RH

*2 NH₃-W: Whole blood only NH₃-P: Plasma only
Na-K-Cl: Plasma, Serum, Whole blood
Other test items: Plasma, Serum

DRI-CHEM NX500 Series

	NX500	NX500i
Electrolyte tests	●	●
Plasma Filter Function	●	-
Automatic dilution	●	●

*DRI-CHEM NX500(Product:FUJI DRI-CHEM NX500/FUJI DRI-CHEM NX500i)
Please contact your local distributor for availability.

Operator ID Editor Kit

Operator ID Editor tool software (for PC) and a USB stick (for data transfer between PC and NX500) for registration and editing operator ID
