Technical specifications
- Printing method
Water-based inkjet, single pass
- Print speed
50m/min | 164 fpm - regardless of the number of colors
- Image resolution
1,200dpi x 1,200dpi
- Maximum image size
733mm, 28,9in
- Substrate width
520mm – 790mm, 20,5in – 31in
- Substrate thickness
12 to 40 microns
- Substrate material
PET, BOPP
- Main application
Flexible packaging for food and non-food, reverse print
- Un-winder
Max roll diameter: 600mm, Max roll weight: 200kg
- Re-winder
Max roll diameter: 600mm, Max roll weight: 200kg
- Dimensions
Width: 12,000mm, Height: 2,400mm, Depth: 2,500mm
- Weight
16,500kg
- Minimum floor space
16,090mm x 8,060mm incl. auxiliary equipment and work-space
- Power-supply voltage
200V and 400V
- Ink
Water-based pigmented ink, 5colors
FP790-Cyan, Magenta, Yellow, Black and White- Pre-conditioner
Water-based coating liquid
