EG-580UT
![](https://asset.fujifilm.com/www/sg/files/2020-05/2c1e7dbe8a72ef7831eb3919425e44de/pic_endoscopic-ultrasonography-system_01.jpg)
![](https://asset.fujifilm.com/www/sg/files/2020-05/cb9adf6c9066aad8a88f5bd8c5bd0bf4/pic_endoscopic-ultrasonography-system_02.jpg)
Endoscopic functions
- Viewing direction
40° (Forward Oblique)
- Field of view
140°
- Observation range
3-100 mm
- Distal end diameter
13.9 mm
- Insertion tube diameter
12.4 mm
- Minimum diameter of instrument channel
3.8 mm
- Bending capability
UP 150° / DOWN 150°
RIGHT 120° / LEFT 120°- Working length
1,250 mm
- Total length
1,550 mm
Ultrasonic functions
- Scanning mode
Color Doppler, Power Doppler, Pulse Doppler, B-mode, M-mode
- Scanning method
Electronic convex scanning method
- Scanning angle
150° (Combination with SU-1)
- Frequency
5 MHz / 7.5 MHz / 10 MHz / 12 MHz
- Product : Ultrasonic Endoscope
- GMDN: 36951
- Generic Name: Flexible ultrasound gastroduodenoscope
EG-580UR
![](https://asset.fujifilm.com/www/sg/files/2020-05/a08ed6bd0656d75ea98e713890165418/pic_endoscopic-ultrasonography-system_03.jpg)
![](https://asset.fujifilm.com/www/sg/files/2020-05/42f3384dcf483bd58b6a442b6bab4876/pic_endoscopic-ultrasonography-system_04.jpg)
Endoscopic functions
- Viewing direction
0°
- Field of view
140°
- Observation range
3-100 mm
- Distal end diameter
11.4 mm
- Insertion tube diameter
11.5 mm
- Minimum diameter of instrument channel
2.8 mm
- Bending capability
UP 190° / DOWN 90°
RIGHT 100° / LEFT 100°- Working length
1,250 mm
- Total length
1,550 mm
Ultrasonic functions
- Scanning mode
Color Doppler, Power Doppler, Pulse Doppler, B-mode, M-mode
- Scanning method
Electronic radial scanning method
- Scanning angle
360° (Combination with SU-1)
- Frequency
5 MHz / 7.5 MHz / 10 MHz / 12 MHz
- Product : Ultrasonic Endoscope
- GMDN: 36951
- Generic Name: Flexible ultrasound gastroduodenoscope
EB-530US
![](https://asset.fujifilm.com/www/sg/files/2020-05/ab5978c3e383b77c776c9f36eae35f17/pic_endoscopic-ultrasonography-system_05.jpg)
![](https://asset.fujifilm.com/www/sg/files/2020-05/8b875e708c805cc03fe5ceaed7addd2a/pic_endoscopic-ultrasonography-system_06.jpg)
Endoscopic functions
- Viewing direction
10° (Forward Oblique)
- Field of view
120°
- Observation range
3-100 mm
- Distal end diameter
6.7 mm
- Insertion tube diameter
6.3 mm
- Minimum diameter of instrument channel
2.0 mm
- Bending capability
UP 130° / DOWN 90°
- Working length
610 mm
- Total length
880 mm
Ultrasonic functions
- Scanning mode
Color Doppler, Power Doppler, Pulse Wave, B-mode, M-mode
- Scanning method
Electronic convex scanning method
- Scanning angle
65° (Combination with SU-1)
- Frequency
5 MHz / 7.5 MHz / 10 MHz / 12 MHz
- Product : Ultrasonic Endoscope
- GMDN: 44921
- Generic Name: Flexible ultrasound bronchoscope
