Main Specifications

Model name		FP-Z5000
DLP chip	Size	0.65" (aspect ratio 16:9)
	Display method	1 chip DLP
	Number of pixels	2,073,600 pixels (1920×1080)
Lens	Type	Folded two-axial rotatable lens
	Shift	Electrical：V±82%　H±35%
	Zoom	Electrical：x1.0 - x1.1
	Focus	Electrical
	Throw ratio (TR value^*1)	0.34 (Wide) - 0.37 (Tele)
	Focal length	f=5.0mm (Wide) - 5.5mm (Tele)
	F No.	F2.4 (Wide) - F2.49 (Tele)
Light source		Laser diode
Brightness		5,000lm
Contrast ratio		1,2000：1
Projected image size		70 - 300 inches, approx. 0.5m - 2.3m
Built-in Speaker		10W×1
Scanning frequency	Horizontal	15K - 102KHz
Scanning frequency	Vertical	23K - 120Hz
Maximum display resolution(W×H)		1920×1080
Input/output terminals	HDMI	3 terminals
	RJ-45	1 terminal
	USB (DC5V Output)	1 terminal TypeA
Usage environment	Operating temperature	0 - 40℃（without condensation）
Usage environment	Storage temperature	-10 to 50℃（without condensation）
Power supply		AC100V - 240V　50/60Hz
Maximum power consumption		700W
Power consumption (on standby)		0.5W
Dimensions		470mm (W) x 375mm (D) x 108mm (H) (when the lens is folded in, excluding protrusions)
Weight		Approx.12 kg
Accessories		Remote control, 2 AAA batteries, lens cap, HDMI cable (1.8m), power supply cable (3.0m), 2 vertical installation stands,basic manual

Specifications and Product appearance are subject to change without notice.
*1　Throw Ratio(TR) is the ratio of the projection distance to the screen width.

■Table of Horizontal Projection Distances

【Aspect Ratio 16: 9】

16:9　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
70	155	×	87	52	-	57	-115	-	28
80	177	×	100	59	-	65	-131	-	32
90	199	×	112	67	-	74	-148	-	36
100	221	×	125	75	-	82	-164	-	40
120	266	×	149	90	-	99	-197	-	48
150	332	×	187	113	-	124	-247	-	60
200	443	×	249	151	-	166	-329	-	80
250	553	×	311	189	-	208	-411	-	100
300	664	×	374	227	-	250	-493	-	120

【Aspect Ratio 16: 10】

16:10　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
70	151	×	85	56	-	62	-112	-	27
80	172	×	97	64	-	71	-128	-	31
90	194	×	109	72	-	80	-144	-	35
100	215	×	121	81	-	89	-160	-	39
120	258	×	145	97	-	107	-192	-	47
150	323	×	182	122	-	134	-240	-	58
200	431	×	242	163	-	179	-320	-	78
250	538	×	303	204	-	225	-400	-	97
300	646	×	363	245	-	270	-480	-	116

【Aspect Ratio 4: 3】

4:3　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
60	122	×	91	54	-	60	-121	-	29
70	142	×	107	64	-	70	-141	-	34
80	163	×	122	73	-	80	-161	-	39
90	183	×	137	82	-	91	-181	-	44
100	203	×	152	92	-	101	-201	-	49
120	244	×	183	110	-	121	-241	-	59
150	305	×	229	138	-	152	-302	-	73
200	406	×	305	185	-	203	-402	-	98
240	488	×	366	222	-	244	-483	-	117

■Table of Vertical Projection Distance

【Aspect Ratio 16: 9】

16:9　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
70	87	×	155	52	-	57	-132	-	-23
80	100	×	177	59	-	65	-151	-	-27
90	112	×	199	67	-	74	-169	-	-30
100	125	×	221	75	-	82	-188	-	-33
120	149	×	266	90	-	99	-226	-	-40
150	187	×	332	113	-	124	-282	-	-50
200	249	×	443	151	-	166	-376	-	66
250	311	×	553	189	-	208	-470	-	-83
300	374	×	664	227	-	250	-565	-	-100

【Aspect Ratio 16: 10】

16:10　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
70	85	×	151	56	-	62	-134	-	-17
80	97	×	172	64	-	71	-153	-	-19
90	109	×	194	72	-	80	-172	-	-22
100	121	×	215	81	-	89	-191	-	-24
120	145	×	258	97	-	107	-230	-	-29
150	182	×	323	122	-	134	-287	-	36
200	242	×	431	163	-	179	-383	-	-48
250	303	×	538	204	-	225	-479	-	-60
300	363	×	646	245	-	270	-574	-	-72

【Aspect Ratio 4: 3】

4:3　Screen				① Projection distance (cm)			② Lens shift (cm)
Size (inches)	Width (cm)	×	Height (cm)	Wide	-	Tele	Lowest	-	Highest
60	91	×	122	54	-	60	-118	-	-4
70	107	×	142	64	-	70	-137	-	-5
80	122	×	163	73	-	80	-157	-	-5
90	137	×	183	82	-	91	-177	-	-6
100	152	×	203	92	-	101	-196	-	-7
120	183	×	244	110	-	121	-236	-	-8
150	229	×	305	138	-	152	-295	-	-10
200	305	×	406	185	-	203	-393	-	-14
240	366	×	488	222	-	244	-471	-	-16

_{＊refers to % difference between the approximate calculation and the numbers in the above table.}

HDMI

Resolution	Signal	Refresh rate (Hz)
VGA	640x480	60
SVGA	800x600	60
XGA	1024x768	60
WXGA	1280x768	60
	1280x800	60
	1366x768	60
SXGA	1280x960	60
SXGA	1280x1024	60
SXGA+	1400x1050	60
WXGA+	1440x900	60
WSXGA+	1680x1050	60
UXGA	1600x1200	60
WUXGA	1920x1200	60
SDTV(480i)	720x480	60
SDTV(480p)	720x480	60
SDTV(576i)	720x576	50
SDTV(576p)	720x576	50
HDTV(720p)	1280x720	60/50
HDTV(1080i)	1920X1080	60/50
HDTV(1080p)	1920x1080	60/50
