[photo] HF-SA Series lenses standing upright and grouped together in a circle

HF-SA Series - Overview

Lens SelectorContact Us
Overview
Case Studies

High resolution lenses

[photo] HF-SA Series lenses standing upright and grouped together in a circle

HF-SA Series

FUJINON HF-SA series is designed to achieve high resolution up to 5 megapixels (3.45µm pixel pitch) compatible with 2/3" sensors.

HF-SA series specification sheet

ModelCompatible format sizesFocal length
(mm)
4/31.111/1.22/31/1.81/21/3
HF12.5SA-1－－－－●●●●12.5
HF16SA-1－－－－●●●●16
HF25SA-1－－－－●●●●25
HF35SA-1－－－－●●●●35
HF50SA-1－－－－●●●●50
HF75SA-1－－－－●●●●75

● Compatible sensor size (std.): Ideal size to maximize the target resolution.

Main features

Low distortion

FUJINON HF-SA series thoroughly minimizes distortion which causes problems in applications requiring high accuracy such as dimension measurement.

[image] Grid view of General MV lens only with spherical lenses and MV lens with an aspherical lens
  • * Simulated image

High performance in close-up shooting

The rear focusing method*1 enables high performance even in close-up shooting.

  • *1 HF12.5SA-1 and HF16SA-1

Low F-number

The low F-number up to F1.4 ensures a clear image even in low light situations.

Enough peripheral light amount

Enough light is captured even at the edges of the image, which contributes to stable inspection accuracy.

Lineups

[photo] HF12.5SA-1 lens on its side

HF12.5SA-1

Focal length [mm]12.5
Iris range (F. no)F1.4-F22
Angle of view38.0°x 29.0° (2/3")
Working Distance*2 (mm)∞‐100
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]295
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]-0.08
Dimension [mm]Φ51×68.5
[photo] HF16SA-1 lens on its side

HF16SA-1

Focal length [mm]16
Iris range (F. no)F1.4-F22
Angle of view30.2°x 22.9° (2/3")
Working Distance*2 (mm)∞‐100
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]285
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]0.11
Dimension [mm]Φ51×70.5
[photo] HF25SA-1 lens on its side

HF25SA-1

Focal length [mm]25
Iris range (F. no)F1.4-F22
Angle of view20.8°x 15.7° (2/3")
Working Distance*2 (mm)∞-100
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]315
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]-0.06
Dimension [mm]Φ51×75.5
[photo] HF35SA-1 lens on its side

HF35SA-1

Focal length [mm]35
Iris range (F. no)F1.4-F22
Angle of view14.0°x 10.5° (2/3")
Working Distance*2 (mm)∞-200
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]185
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]0.07
Dimension [mm]Φ51×48.5
[photo] HF50SA-1 lens on its side

HF50SA-1

Focal length [mm]50
Iris range (F. no)F1.8-F22
Angle of view9.7°x 7.3° (2/3")
Working Distance*2 (mm)∞-400
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]240
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]0.08
Dimension [mm]Φ51×55.5
  • *2 From front of lens barrel
  • *3 Sensor size (std.): Ideal size to maximize the target resolution.
  • *4 Sensor size (max.): Adaptable sensor size varies depending on the model. Please check the amount of light and resolution on the edges pertaining to your particular application.
[photo] HF75SA-1 lens on its side

HF75SA-1

Focal length [mm]75
Iris range (F. no)F1.8-F22
Angle of view6.7°x 5.0° (2/3")
Working Distance*2 (mm)∞-900
Operation of focusManual
Operation of irisManual
Filter thread [mm]M49 x 0.75
MountC-mount
Weight (approx.) [g]305
Sensor size (std.)*32/3" (3.45μm)
Sensor size (max.)*42/3" (3.45μm)
TV distortion [%]0.01
Dimension [mm]Φ51×76
