Dye-sublimation Printer

ASK-500 - Specifications

NEW

Now with even easier supply replacement and more print-size flexibility, the ASK-500 opens up new photo business possibilities.

Specifications
Model

ASK-500

Printing method

Dye-sublimation thermal transfer

Surface finish*1

Glossy type, Matte type

Printing resolution

300 × 300 dpi

Print speed*2

4” × 6” : approx. 12.0 sec*3
6” × 8” : approx. 22.5 sec
3.5” × 5” : approx. 11.1 sec*3
5” × 7” : approx. 20.8 sec

Foot print

0.105 m2

Dimensions (W × D × H)

11.8” × 13.8” × 11.1” (300 mm × 350 mm × 281 mm)

Weight

Approx. 14 kg (31 lb.)

Interface

Hi-Speed USB ver. 2.0

Power supply

100V-240V    AC 50/60Hz

Accessories

Paper strip bin, Paper tray, Quick Set Up Guide, Safety Guide

  • * Specifications are subject to change without notice.
  • *1 Both are available with one media.
  • *2 Does not include data transfer, printer intialization and paper feed times.
  • *3 Single print speed of 2-up print.
Consumables Lineup
ModelPrint sizeNumber of prints (max)*
ASK-500 MEDIA SET 684 × 6 in. (102 × 152 mm)750 prints
6 × 8 in. (152 × 203 mm)375 prints
ASK-500 MEDIA SET 573.5 × 5 in. (89 × 127 mm)800 prints
5 × 7 in. (127 × 178 mm)400 prints
  • * Maximum number of prints when printing the same size on one media.
