UV Light Distribution Mapping System

FUD-7010E

NEW
Contact Us Trial Version Download

Specifications

Product Name

FUJIFILM UV LIGHT DISTRIBUTION MAPPING SYSTEM for UVSCALE

Model

FUD-7010E ver.1.4

Components

Exclusive software (CD- ROM), Dedicated cover, Calibration sheet

Measurable UV lamp

High-pressure mercury lamp, metal halide lamp, low-pressure mercury lamp, UV-LED (365 nm)

Main Functions

Analyzing UVSCALE images (measuring accumulated light amount, displaying light amount distribution, saving data, data export)

Scan Sizes

Depending on the scanner usedDepending on the scanner used

Resolution

0.125mm (200dpi) 0.03125mm (800dpi)

Applicable Scanner

Epson V370, V37, Perfection V600 and Perfection V850

Recommended Software Environment

OS

Windows10 Home/Pro（32Bit/64Bit）
Windows11 Home/Pro（64Bit）

CPU

2GHz or Higher

Memory

2GB or more

HDD

32GB or more

Display

XGA or better, 65,000 colors or more
