[photo] FDR D-EVO II C35/C43/G35/G43 DR Panel

FDR D-EVO II C35/C43/G35/G43 - Overview

A rectangular large-sized DR panel full of multiple functions in a lightweight body.

Contact Us
Overview
DR Accessory

The content on this page is intended to healthcare professionals and equivalents.

Smart Function - Pursuing ease of use through versatile functionality

[photo] LED status displays for different functions of machine

1. Improved insertion through shell design

The shell design, with its curved sides, allows for easier insertion into patient beds. The easy-to-grasp shape allows for easy pick up even when placed flat, improving task efficiency.

2. Five-colored side-center LEDs to improve distinguishability

Equipped with LEDs at the center of each of the four sides of the detector that makes it easy to check the center position during imaging. Select from five colors (blue, pink, orange, lime-yellow, and purple) that make it easier to distinguish devices when using multiple detectors. In sleep mode, the side-center LEDs switch to a gentle flashing pattern that allows you to see the state of the detector at a glance.

3. Easy-to-see LED status display

The back of the detector is equipped with an LED lamp that displays remaining battery status. This allows easy checks of remaining battery, and eliminates worries when using the detector.

[photo] LED battery status display

4. Maximum 36 hours of standby time with the new sleep function

The sleep mode provides a maximum 7.5 hours of standby time, whereas the newly added extra sleep mode provides up to 36 hours of standby time.In sleep mode, the center LED on the side of the detector flashes slowly to indicate the detector status at a glance.

[image] Bar graph for sleep mode of conventional device compared to FDR D-EVO II

5. Works together with the console to display the detector status display the detector status connection

The docking stand works together with the console to display the detector's “Ready” status and identify color using the LEDs. This makes it easy to check the current state of the detector even from far away.

6. "SmartSwitch" Technology

[logo] SmartSwitch

The “SmartSwitch” technology allows automatic X-ray detection.
With “SmartSwitch,” the FDR ES no longer requires connection between the X-ray generator and DR to automatically detect the X-ray exposure and begin image acquisition.

Smart Protection - Combines waterproofing, and durability for additional peace of mind even in the tough medical environments.

IPX6 waterproofing

Structured to prevent the infiltration of liquids, the device conforms to IPX6 and can withstand jets from any direction*1. There is no need to worry that fluids such as blood or vomit could enter the device.

[photo] Water sprayed on upright standing device

A frame structure that increases durability — 310kg load capacity

The innovative SRM*2 frame realizes a lightweight design combined with a 310kg load capacity on all surfaces by reinforcing the frame internally with ribs. This also improves the flex resistance of the display detector.

[photo] Internal SRM frame
  • *1 Because of product characteristics, these effects cannot always be guaranteed into the future.
  • *2 Shell-shape with rib magnesium-alloy

Smart Mobility: Superior mobility with lightweight body allows use in a variety of medical settings.

lightweight body

Designed to be lightweight, weighing only 2.5 kg*2 (G35 size with battery) through the magnesium-alloy shell-type frame (SRM*3 frame). Can easily be placed behind a patient

Suitable for various location use with an expanded spectrum

Supports 2.4GHz and 5GHz (W52 / 53 / 56 / 58)*4 spectrum.

Allows detector-only image storage

The detector itself can store up to 100 images in internal memory. This eliminates the work of carrying around multiple CR cassettes found in conventional systems. Furthermore, it allows you to perform rapid imaging, such as at night or during an emergency.

[image] Store up to 100 images on internal memory of FDR D-EVO II
  • *2 G43：3.1kg, C35：2.6kg, C43：3.2kg, with battery
  • *3 Shell-shape with rib magnesium-alloy
  • *4 It depends on the regulation of each country which the wireless band is allowed to be used.

Fujifilm's exclusive technology for achieving High Quality Images

ISS System reading technology

Equipped with an indirect conversion system called ISS method which bonds optical sensors (TFT) to the X-ray irradiation side unlike traditional flat detector displays. This greatly suppresses scattering and attenuation of X-ray signals, creating a sharp image with low X-ray dose. By applying flexible film to device detector, FDR D-EVO II has achieved DQE 54% (CsI scintillator), 31% (GOS scintillator)  (1Lp/mm-RQA5 1mR)

Conventional method

ISS system reading technology

Fujifilm noise reduction circuit improves detector sensitivity in high absorption regions

The uniquely developed noise reduction circuit reduces noise in the image. In particular, granularity of low-concentration regions such as the heart and mediastinum is dramatically improved.

Advanced Image Processing

FUJIFILM has over 30 year’s experience the invention of the world’s first CR system in defining the latest technology to provide optimized X-ray imaging.
Simpler, more efficient with improved workflow for the radiographer our advanced image processing provides higher diagnostic value with reduced impact for the patients.

Compatible with Console Advance, employing advanced image processing technology to provide optimized X-ray image

Simpler, more efficient with improved workflow for the Radiographer, our advanced image processing high quality image with reduced impact for the patients.

Virtual Grid

Grid like Image quality without using a grid

  • * Optional

Virtual Grid is an image processing software that corrects for the effects of scatter radiation that otherwise reduce image contrast and clarity. Without the need for an anti-scatter grid, this software quickly predicts and then corrects for the effects of scattered radiation...
creating high quality images.

Dynamic Visualization II

  • * Optional

Advanced recognition algorithms automatically adjust contrast and density for individual body parts based on calculation of estimated 3D image data.

Products Name : FDR D-EVO II（Model name : DR-ID 1200)

  • * Fujifilm makes no representation that products on this website are commercially available in all countries.
  • * Approved uses of products vary by country and region.
  • * Specifications and appearance of products are subject to change without notice.
