2/3" Studio / Field Box Lenses

Lineups 4K Plus Premier Series

UA80x9BESM 1.2x EXT

Advanced optical performance that enables 4K compatibility under any shooting conditions
Enabling further telephoto shooting by newly developed incorporating a 1.2x extender
9-blade round iris enabling natural bokeh in images
Featuring the popular optical stabilization mechanism
Equipped with 16bit encoder for virtual device

Specifications

Model Name: UA80x9BESM 1.2x EXT
Focal length: [1x]
9-720mm
[1.2x]
10.8-864mm
[2x]
18-1440mm
Zoom ratio: 80x
Extender: 1.2x, 2x
Maximum relative aperture (F-no.): 1:1.7 (9-350mm) 1:3.5 (720mm)
Minimum object distance (M.O.D.) from front lens: 3.7m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
9mm 3501mm x 1968mm
720mm 46mm x 26mm
[1.2x]
10.8mm 3009mm x 1692mm
864mm 39mm x 22mm
[2x]
18mm 1816mm x 1021mm
1440mm 23mm x 13mm
Angular field of view 16 : 9 Aspect ratio: [1x]
9mm 56.1°× 33.3°
720mm 0.8° × 0.4°
[1.2x]
10.8mm 47.9° × 28.0°
864mm 0.6° × 0.4°
[2x]
18mm 29.8° × 17.0°
1440mm 0.4° × 0.2°
Approx. Size: 258 x 264 x 610mm（H×W×L)
Approx. Mass: 23.5kg

UA125×8BESM

Achieved both highest magnifications*² 125x and 4K　optical performance
Perfect for live sports coverage with the optical 107× zoom
Unique optical image stabilization mechanism
Vivid color reproduction and HDR-based rich tonal gradation for superior video production
Natural bokeh achieved with 9blade diaphragm
Standard feature of a built-in 16bit encoders

Model Name: UA125×8BESM
Focal Length: [1x]
8-1000mm
[2x]
16-2000mm
Zoom Ratio: 125x
Extender: 2 x
Maximum Relative Aperture (F-No.): 1:1.7(8-340mm) 1:5.0(1000mm)
Minimum Object Distance (M.O.D.) from Front Lens: 3.0m
Object Dimensions at M.O.D. 16 : 9 Aspect Ratio: [1x]
8mm 3198mm × 1799mm
1000mm 27mm × 15mm
[2x]
16mm 1677mm × 943mm
2000mm 14mm × 8mm
Angular Field of View 16 : 9 Aspect Ratio: [1x]
8mm 61.9° x 37.2°
1000mm 0.55° x 0.31°
[2x]
16mm 33.4° x 19.1°
2000mm 0.27°x 0.15°
Approx. Size: 258 x 264 x 635mm（H×W×L）
Approx. Mass: 26.6Kg

4K Premier Series

UA27x6.5BESM

Advanced optical performance with 4K compatibility across the zoom range
Achieving natural bokeh with the adoption of nine aperture blades
27x zoom from 6.5mm at wide angle to 180mm at telephoto for covering a wide variety of scenes
Maximum aperture ratio of f1.5 to draw out full optical performance with 4K compatibility
Equipped with 16-bit encoder^*1

Specifications

Model Name: UA27x6.5BESM
Focal Length: [1x]
6.5-180mm
[2x]
13-360mm
Zoom ratio: 27x
Extender: 2x
Maximum relative aperture (F-no.): 1:1.5(6.5-123mm) 1:2.2(180mm)
Minimum object distance (M.O.D) from the front lens element: 0.6m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
6.5mm   1063 x 597mm
180mm   38 x 21mm
[2x]
13mm   529 x 297mm
360mm   20 x 11mm
Angular field of view 16 : 9 Aspect ratio: [1x]
6.5mm   72.8° x 45.0°
180mm   3.1° x 1.7°
[2x]
13mm   40.5° x 23.4°
360mm   1.5° x 0.9°
Approx. Size: 258mm x 264mm x 536mm (H x W x L)
Approx. Mass: 22.8kg

UA70x8.7BESM

70x zoom lens covering the most frequently-used focal lengths from 8.7mm in wide angle to 610mm in telephoto
Cutting-edge optical design to produce dynamic 4K footage in a diverse range of scenes
Natural bokeh achieved with nine-blade diaphragm
Stock-standard 16-bit encoder

Specifications

Model Name: UA70x8.7BESM
Focal Length: [1x]
8.7mm-610mm
[2x]
17.4mm-1220mm
Zoom ratio: 70x
Extender: 2x
Maximum aperture ratio: 1:1.7(8.7-340mm) 1:3.05(610mm)
Minimum object distance (M.O.D) from the front lens element: 3.05m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
8.7mm 2,935mm x 1,651mm
610mm 44mm x 25mm
[2x]
17.4mm 1,537mm x 865mm
1220mm 23mm x 13mm
Angular field of view 16 : 9 Aspect ratio: [1x]
8.7mm 57.7° x 34.4°
610mm 0.9° x 0.5°
[2x]
17.4mm　30.8° x 17.6°
1220mm 0.5° x 0.3°
Approx. Size: 258 x 264 x 610mm (H x W x L)
Approx. Mass: 23.8kg

UA107x8.4BESM

The world's first *² 4K-compatible broadcast lens that features the AF function
Perfect for live sports coverage with the optical 107× zoom
Unique optical image stabilization mechanism
Vivid color reproduction and HDR-based rich tonal gradation for superior video production
Natural bokeh achieved with 9blade diaphragm
Standard feature of a built-in 16bit encoders

Specifications

Model Name: UA107x8.4BESM
Focal Length: [1x]
8.4-900mm
[2x]
16.8-1800mm
Zoom ratio: 107x
Extender: 2x
Maximum Relative Aperture (F-No.): 1:1.7 (8.4-340mm) 1:4.5 (900mm)
Minimum object distance (M.O.D.) from front lens: 3.05m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
8.4mm 3053mm x 1717mm
900mm 30mm x 17mm
[2x]
16.8mm 1594mm x 896mm
1800mm 15mm x 9mm
Angular field of view 16 : 9 Aspect ratio: [1x]
8.4mm 59.4° × 35.6°
900mm 0.6° × 0.3°
[2x]
16.8mm 31.9° × 18.2°
1800mm 0.3° × 0.2°
Approx. Size: 258mm x 264mm x 610mm
Approx. Mass: 23.9kg

UA107x8.4BESM AF

The world's first *² 4K-compatible broadcast lens that features the AF function
Perfect for live sports coverage with the optical 107× zoom
Unique optical image stabilization mechanism
Vivid color reproduction and HDR-based rich tonal gradation for superior video production
Natural bokeh achieved with 9blade diaphragm
Standard feature of a built-in 16bit encoders

Model Name: UA107x8.4BESM AF
Focal Length: [1x]
8.4-900mm
[2x]
16.8-1800mm
Zoom Ratio: 107 x
Extender: 2 x
Maximum Relative Aperture (F-No.): 1:1.7(8.4-340mm) 1:4.5(900mm)
Minimum Object Distance (M.O.D.) from Front Lens: 3.05m
Object Dimensions at M.O.D. 16 : 9 Aspect Ratio: [1x]
8.4mm 3052mm x 1717mm
900mm 30mm x 17mm
[2x]
16.8mm 1594mm x 896mm
1800mm 15mm x 9mm
Angular Field of View 16 : 9 Aspect Ratio: [1x]
8.4mm 59.4°x35.6°
900mm 0.6°x0.3°
[2x]
16.8mm 31.9°x 18.2°
1800mm 0.3°x 0.2°
Approx. Size: 258 x 264 x 670mm(HxWxL)
Approx. Mass: 26.0kg

*1 The sensor for converting position information into digital signals; Zoom and focus position data is divided in 16-bit resolution and output as electric signals.

*2 Among 4K-compatible broadcast lenses as of October 1st, 2019, according to Fujifilm
