Specifications
- Model
ASK-500
- Printing method
Dye-sublimation thermal transfer
- Surface finish*1
Glossy type, Matte type
- Printing resolution
300 × 300 dpi
- Print speed*2
4” × 6” : approx. 12.0 sec*3
6” × 8” : approx. 22.5 sec
3.5” × 5” : approx. 11.1 sec*3
5” × 7” : approx. 20.8 sec- Foot print
0.105 m2
- Dimensions (W × D × H)
11.8” × 13.8” × 11.1” (300 mm × 350 mm × 281 mm)
- Weight
Approx. 14 kg (31 lb.)
- Interface
Hi-Speed USB ver. 2.0
- Power supply
100V-240V AC 50/60Hz
- Accessories
Paper strip bin, Paper tray, Quick Set Up Guide, Safety Guide
- * Specifications are subject to change without notice.
- *1 Both are available with one media.
- *2 Does not include data transfer, printer intialization and paper feed times.
- *3 Single print speed of 2-up print.
Consumables Lineup
Model | Print size | Number of prints (max)* |
---|---|---|
ASK-500 MEDIA SET 68 | 4 × 6 in. (102 × 152 mm) | 750 prints |
6 × 8 in. (152 × 203 mm) | 375 prints | |
ASK-500 MEDIA SET 57 | 3.5 × 5 in. (89 × 127 mm) | 800 prints |
5 × 7 in. (127 × 178 mm) | 400 prints |
- * Maximum number of prints when printing the same size on one media.
