LB150 Series

NEW

Contact Us Catalog

Lineups

25 × 150 MT-SX

The large aperture 150mm objective lenses ensure excellent visibility at dusk or night.
High-quality EBC multi-coating for high resolution and sharp image throughout the field of view.
In addition to their airtight, waterproof structure, these binoculars are corrosion resistant, making them durable enough to withstand temperatures ranging from -20℃ to +50℃.
Fujinon recommends the use of dedicated mount and tripod.

[photo] 25 × 150 MT-SX binoculars

Specifications

Magnification: 25
Objective diameter (mm): 150
Field of view (°): 2.7
Apparent field of view (°) ^*1: 61
Field of view at 1000m (m): 47
Exit pupil: 6
Relative Brightness: 36
Eye relief (mm): 18.6
Minimum Focus Distance (m) ^*2: 125
Height (mm): 962
Width (mm): 365
Depth (mm): 525
Weight (g) (w/o Battery): 18,500
Adustment range for interpupillary distance (mm): 60-70
Dioptric adjustment range (±mm): −7 - +3
Focus type: IF
Water resistant^*3: 2m-5min
Battery: -
Operationg temperature: −20℃ - +50℃

25 × 150 ED-SX(made to order)

The large aperture 150mm objective lenses ensure excellent visibility at dusk or night.
High-quality EBC multi-coating for high resolution and sharp image throughout the field of view.
In addition to their airtight, waterproof structure, these binoculars are corrosion resistant, making them durable enough to withstand temperatures ranging from -20℃ to +50℃.
The 25x150ED-SX, 40x150ED-SX and 25x150EM-SX have special ED lenses to reduce color aberration for a clear picture even at high magnification.
Fujinon recommends the use of dedicated mount and tripod.

[photo] 25 × 150 ED-SX binoculars (made to order)

Specifications

Magnification: 25
Objective diameter (mm): 150
Field of view (°): 2.7
Apparent field of view (°) ^*1: 61
Field of view at 1000m (m): 47
Exit pupil: 6
Relative Brightness: 36
Eye relief (mm): 18.6
Minimum Focus Distance (m) ^*2: 125
Height (mm): 962
Width (mm): 365
Depth (mm): 525
Weight (g) (w/o Battery): 18,500
Adustment range for interpupillary distance (mm): 60-70
Dioptric adjustment range (±mm): −7 - +3
Focus type: IF
Water resistant^*3: 2m-5min
Battery: -
Operationg temperature: −20℃ - +50℃

40 × 150 ED-SX(made to order)

The large aperture 150mm objective lenses ensure excellent visibility at dusk or night.
High-quality EBC multi-coating for high resolution and sharp image throughout the field of view.
In addition to their airtight, waterproof structure, these binoculars are corrosion resistant, making them durable enough to withstand temperatures ranging from -20℃ to +50℃.
The 25x150ED-SX, 40x150ED-SX and 25x150EM-SX have special ED lenses to reduce color aberration for a clear picture even at high magnification.
Fujinon recommends the use of dedicated mount and tripod.

[photo] 40 × 150 ED-SX binoculars (made to order)

Specifications

Magnification: 40
Objective diameter (mm): 150
Field of view (°): 1.7
Apparent field of view (°) ^*1: 61.4
Field of view at 1000m (m): 30
Exit pupil: 3.8
Relative Brightness: 14.1
Eye relief (mm): 15
Minimum Focus Distance (m) ^*2: 320
Height (mm): 946
Width (mm): 365
Depth (mm): 525
Weight (g) (w/o Battery): 18,500
Adustment range for interpupillary distance (mm): 60-70
Dioptric adjustment range (±mm): −7 - +3
Focus type: IF
Water resistant^*3: 2m-5min
Battery: -
Operationg temperature: −20℃ - +50℃

15 × 80 MT-SX

High-quality EBC multi-coating for high resolution and sharp image throughout the field of view.
In addition to their airtight, waterproof structure, these binoculars are corrosion resistant, making them durable enough to withstand temperatures ranging from -20℃ to +50℃.
Fujinon recommends the use of dedicated mount and tripod.
Bundled with a case.

[photo] 15 × 80 MT-SX binoculars

Specifications

Magnification: 15
Objective diameter (mm): 80
Field of view (°): 4
Apparent field of view (°) ^*1: 55.3
Field of view at 1000m (m): 70
Exit pupil: 5.3
Relative Brightness: 28.4
Eye relief (mm): 15.7
Minimum Focus Distance (m) ^*2: 45
Height (mm): 510
Width (mm): 225
Depth (mm): 455
Weight (g) (w/o Battery): 7,060
Adustment range for interpupillary distance (mm): 58-72
Dioptric adjustment range (±mm): −4 - +2
Focus type: IF
Water resistant^*3: 2m-5min
Battery: -
Operationg temperature: −20℃ - +50℃

*1 Apparent field of view based on ISO14132-1:2002
*2 MOD may differ depends on the viewer's sight in case of Indivisual focus.
*3 Do not mean it can be used in water.

Bundled items: Objective lens cap and winged eyecup.

* 15 x 80 MT-SX bundled with a case.
